CX-ML-1652
MBQ
Overview
0.5" tweeter with PEI dome and neodymium magnet.
Shallow mounting depth.
High performance woofer with steel basket, ferrite magnet, Polypropylene cone, NBR surround and rubber magnet cover.
Product Description
Specifications
Woofer | |
Max. Power Handling | 40W |
RMS Power Handling | 20W |
Impedance | 4Ω |
Frequency Response | 70Hz-20kHz |
Sensitivity (1W/1m) | 88dB |
Cone Material | Injected Polypropylene |
| Dust Cap Material | Polypropylene |
Surround Material | NBR |
Magnet Type | Ferrite |
Basket Material | Stamped Steel |
Voice Coil Diameter | 25.5mm |
Mounting Depth | 56mm |
Tweeter | |
Tweeter Size | 0.5" |
Voice Coil Diameter | 13.28mm |
Impedance | 4Ω |
Frequency Response | 1700Hz-20kHz |
Sensitivity (1W/1m) | 89dB |
Tweeter Cone Material | PEI |
Housing Material | ABS |
Magnet Type | Neodymium |
