DSP-MM16161-A
MBQ
Product Description
Specifications
| Core Audio | Channels | 16 Channels |
| Built-in Equalizer | 31-Band EQ | |
| Built-in Amplifier Type | Class AB + D | |
| Power Output (@ 4Ω) | Max. Output Power | 50 W × 12 + 100 W × 4 |
| RMS Output Power | 20 W × 12 + 50 W × 4 | |
| Power Output (@ 2Ω) | Max. Output Power | 75 W × 12 + 150 W × 4 |
| RMS Output Power | 30 W × 12 + 75 W × 4 | |
| Load & Voltage | Load Impedance | 2Ω – 4Ω |
| Working Voltage | DC 10 V – 15 V | |
| Audio Inputs | High-Level (Speaker) Input | 16 Channels |
| Low-Level (RCA) Input | 2 Channels | |
| Bluetooth Input | BT 5.0 | |
| Digital Player (Music Streamer) | Yes | |
| Optical Input | Yes | |
| Input Sensitivity | Low-Level Input | 8 V |
| High-Level Input | 15 V – 30 V | |
| Audio Outputs | High-Level (Speaker) Output | 16 Channels |
| Low-Level (RCA) Output | 16 Channels | |
| Output Performance | Output Voltage (Low-Level) | 9 V |
| Sampling Rate | 96 kHz / 24-bit | |
| Total Harmonic Distortion (THD) | ≤ 0.02% | |
| Performance | Frequency Response | 20 Hz – 20 kHz |
| Signal-to-Noise Ratio (SNR) | > 100 dB | |
| Bass Gain | 40 dB (Range: -20 dB to +20 dB) | |
| Control & Auto | Auto Turn ON/OFF | ACC / High-Level Input Trigger |
| Physical | Dimensions (L × W × H) | 238 × 248 × 50 mm |
