AS-MM-2801
MBQ
Overview
Built-in peak power 420Watts Class D amplification
Rigid sealed cast aluminum shallow enclosure
Plug and Play connection system, easy to hook up
Automatic switch-on
Completely hidden installation and out of sight
Designed to fit right into above 15-inches spare wheel
Provided screws for the subwoofer fixing
Remote control provided for volume control, low-pass control and phase switch.
Product Description
Specifications
| Speaker Size | 11" Diameter | |
| Impedance | (4+4) Ohms | |
| Sensitivity (1W/1m) | 85 dB | |
| Cone Composition | Fiber Reinforced ABS | |
| Magnet Type | Ferrite | |
| Enclosure Housing Material | Aluminum | |
| Enclosure Dimensions (L×W×H) | 360 × 360 × 120 mm | |
| Enclosure Net Weight (Without accessories) | 7.4 kg | |
| Amplifier | Amplifier Technology | Class D |
| Normal Output Power (RMS) | 320 W | |
| Max. Output Power | 420 W | |
| Signal-to-Noise Ratio (SNR) | > 90 dB | |
| Frequency Response | 20 Hz – 150 Hz | |
| Low Pass Filter (LPF) | 50 Hz – 150 Hz | |
| Voltage Requirement | 12 V DC (Range: 10 V – 14 V) | |
| Phase Switch | 0° / 180° | |
| Auto On/Off | High Level Input Only | |
| Fuse Rating | 30 A | |
| Total Harmonic Distortion (THD) | < 0.4% | |
| Variable Bass Boost | 0 – 12 dB | |
| Protection Features | Thermal, Short Circuit, Overload Protection |
