AMP-MM4100-A
MBQ
Overview
High Efficiency with High Power/Size Rate and S/N Ratio
Optimized Circuit Design with Close to 0 Background Noises
120Wx4@4Ω RMS Output Power (AMP-MM4100-A)
120Wx6@4Ω RMS Output Power (AMP-MM6100-A)
Product Description
Specifications
Model Number | AMP-MM4100-A |
RMS Output Power @8Ω | 70Wx4 |
RMS Output Power @4Ω | 120Wx4 |
RMS Output Power @2Ω | 150Wx4 |
RMS Output Power Bridged@4Ω | 300Wx2 |
Amplifier Technology | Class AB |
PCB Board Layer | x2 |
Inputs | 4CH Low-level Inputs |
Input Sensitivity | 0.25V-15V |
Input Impedance | 10kΩ |
Outputs | 4CH High-level Outputs |
Frequency Response | 4Hz-100kHz |
Total Harmonic Distortion(THD) | <0.1% |
Signal-to-Noise Ratio | >113dB |
Damping Factor | >200 |
Separation | >76dB |
Operating Voltage | 10V-15V |
Max.Current Draw | 60A |
Idling Current | 0.75A |
Fuse | 30Ax2 |
Heatsink Material | Extruded Aluminum |
Dimensions | 255x170x55mm |
Net Weight | 2.8kg |
